MIL-PRF-83755B
TABLE I: Requirements cross-reference matrix
Requirement
Verification
Requirement
Verification
3.3
4.6.1, 476
3.9.3
4.6.2
3.3.1
4.6.1
3.9.4
4.7.5
3.3.2
4.6.1
3.9.5
4.6.5
3.4.1
4.6.4
3.9.6
4.7.1
3.4.2
4.6.1
3.9.7
4.7.2
3.4.3
4.7.7
3.9.8
4.6.1
3.5
4.6.1
3.10
4.6.1
3.6
4.6.1
3.11
4.6.1
3.7
4.6.1
3.12
4.7.8
3.8
4.6.1
3.13.1
4.7.3
3.9.1
4.6.1
3.13.2
4.7.4
3.9.2
4.6.3
4.6 Individual tests.
4.6.1 Examination. Each flight check list holder shall be examined to determine conformance
with materials, weight, dimensions, components, lens color, scroll text indicator, capacity,
interchangeability, item identification, and case color.
4.6.2 Movement of the scroll check list. With each flight check list holder fully assembled and a
scroll check list mounted in the flight check list holder, the scroll checklist shall be moved one
foot in one direction and then one foot in the opposite direction. The scroll check list shall not
contact the light source or the lens during movement or when it is stationary. When the scroll
check list is stationary, it shall be taut.
4.6.3 Visibility. This test shall be conducted in a dark room with no sources of light. With the
flight check list holder fully assembled, a printed scroll check list mounted in the flight check list
holder, and the flight checklist holder light at full power, the print on the scroll check list shall be
readable through the lens.
4.6.4 Electrical wiring and terminals. The terminals on the flight check list holder shall be
connected to a 28 Vdc source using MS25036 terminal lugs. The light shall be adjusted from the
off position through full power using the light control. As the light control is moved, the light
shall become continuously brighter until the light control reaches the full power position.
Deliberate movement of the light control shall be required move the light control from the off
position. The voltage across the terminals of the holder shall measure 28 ± 1 Vdc. This test shall
be conducted on the terminals on each end of the flight check list holder case.
7
